GSC Beehive Valve Springs and Titanium Retainer Set for Subaru EJ Engines
- SKU:
- GSC5043
- Proposition 65:
P65 WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov.
GSC Beehive Valve Springs and Titanium Retainer Set for Subaru EJ Engines
Some might find that the beehive spring design is new, but it has been used commonly in many OE engines as well as in all of the NASCAR and F1 engines of today. Why? The beehive shape is more stable than standard single or dual cylindrical springs. The beehive design which incorporates an ovate wire is more than capable of the performance demands that were previously only matched by a Dual Springs. With the smaller and lighter retainer used on the beehive valve spring allow for higher RPM and more valve control. So beehive valve springs, with there lighter weight retainers allow for engines to rev quicker and maintain a more stable valve motion than the traditional cylindrical springs of yesteryear.
Benefits:
- Rev faster
- Lighter components
- More durable design
- Less stress on valvetrain components
- Lower spring frequency for more precise valve control.
- More valve control equals more aggressive cam profiles
- Nano peened for faster break in and less stressed springs
- All of these items help to return more power for you to enjoy!
The GSC 5043 Beehive valve spring set, and Grade 5 Titanium retainers kit is capable of 9500+ RPMS, with as much as 11.5mm lift cams.
5043 Beehive Spring Pressure:
- Seat: 85 lbs @ 1.369" (34.8mm) Valve Lift
- 225lbs @ .433" (11mm) Valve Lift
- Coil bind @ .550" (14mm) Valve Lift
5043 Beehive Rev and Boost range (using an S3 profile camshaft set)
- Max RPM: 9,500
- Max boost: 35psi+
Model Year & Fitment
- 2002 Subaru WRX
- 2003 Subaru WRX
- 2004 Subaru WRX
- 2005 Subaru WRX
- 2006 Subaru WRX
- 2007 Subaru WRX
- 2008 Subaru WRX
- 2009 Subaru WRX
- 2010 Subaru WRX
- 2011 Subaru WRX
- 2012 Subaru WRX
- 2013 Subaru WRX
- 2014 Subaru WRX
- 2004 Subaru STI
- 2005 Subaru STI
- 2006 Subaru STI
- 2007 Subaru STI
- 2008 Subaru STI
- 2009 Subaru STI
- 2010 Subaru STI
- 2011 Subaru STI
- 2012 Subaru STI
- 2013 Subaru STI
- 2014 Subaru STI
- 2015 Subaru STI
- 2016 Subaru STI
- 2017 Subaru STI
- 2018 Subaru STI
- 2019 Subaru STI
- 2020 Subaru STI
- 2005 Subaru Legacy GT
- 2006 Subaru Legacy GT
- 2007 Subaru Legacy GT
- 2008 Subaru Legacy GT
- 2009 Subaru Legacy GT
- 2010 Subaru Legacy GT
- 2011 Subaru Legacy GT
- 2012 Subaru Legacy GT
- 2004 Subaru Forester XT
- 2005 Subaru Forester XT
- 2006 Subaru Forester XT
- 2007 Subaru Forester XT
- 2008 Subaru Forester XT
- 2009 Subaru Forester XT
- 2010 Subaru Forester XT
- 2011 Subaru Forester XT
- 2012 Subaru Forester XT
- 2013 Subaru Forester XT
